razor barbed wire/barbed wire concertina/galvanized razor wire(ISO9001 factory)/razor blaed wire fencing
Razor wire is also named concertina coils or razor type barbed wire. It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel sheets or stainless steel sheets. With beautiful and sharp blades and strong core wire, razor wire has the features of secure fencing, easy installation, age resistance and other properties.
Materials of razor barbed wire:
- High carbon steel sheets and wire
- galvanized steel sheet and wire
- staniless steel sheet and wire.
Razor Barbed Wire/Concentina Wire
| Razor Barbed Wire Specification |
| Reference | Thickness | Wire | Blade | Blade | Blade |
| Number | mm | Diameter | Length | Width | Spacing |
| BTO-10 | 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
| BTO-12 | 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
| BTO-15 | 0.5±0.05 | 2.5±0.1 | 15±1 | 15±1 | 33±1 |
| BTO-18 | 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
| BTO-22 | 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
| BTO-28 | 0.5±0.05 | 2.5±0.1 | 28±1 | 15±1 | 45±1 |
| BTO-30 | 0.5±0.05 | 2.5±0.1 | 30±1 | 18±1 | 46±1 |
| CBT-60 | 0.6±0.05 | 2.5±0.1 | 60±2 | 21±1 | 100±2 |
| CBT-65 | 0.6±0.05 | 2.5±0.1 | 60±2 | 21±1 | 100±2 |
| Outer diameter | No.of Loops | Standard Length | Type | Notes |
| per Coil |
| 450mm | 33 | 7M-8M | CBT-65 | Single coil |
| 500mm | 41 | 10M | CBT-65 | Single coil |
| 700mm | 41 | 10M | CBT-65 | Single coil |
| 960mm | 54 | 11M-15M | CBT-65 | Single coil |
| 500mm | 102 | 15M-18M | BTO-12.18.22.28.30 | Cross type |
| 600mm | 86 | 13M-16M | BTO-12.18.22.28.30 | Cross type |
| 700mm | 72 | 12M-15M | BTO-12.18.22.28.30 | Cross type |
| 800mm | 64 | 13M-15M | BTO-12.18.22.28.30 | Cross type |
| 960mm | 52 | 12M-15M | BTO-12.18.22.28.30 | Cross type |
Features:
•Easy and quickly Installation
•Low cost then the fence that with post
•More security than barbed wire
| Specifications of Razor Barbed Wire Mesh |
| Outside Diameter | No. of Loops | Standard Length per Coil | Type | Notes |
| 450mm | 33 | 7-8M | CBT-60.65 | Single coil |
| 500mm | 56 | 12-13M | CBT-60.65 | Single coil |
| 700mm | 56 | 13-14M | CBT-60.65 | Single coil |
| 960mm | 56 | 14-15M | CBT-60.65 | Single coil |
| 450mm | 56 | 8-9M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 500mm | 56 | 9-10M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 10-11M (3 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 600mm | 56 | 8-10M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 700mm | 56 | 10-12M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 800mm | 56 | 11-13M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 900mm | 56 | 12-14M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 960mm | 56 | 13-15M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
| 980mm | 56 | 14-16M (5 CLIPS) | BTO-10.12.18.22.28.30 | Cross type |
Packaging-Razor Barbed Wire
Packing: Bulk, simple packing and carton packing.
Simple packing: inside is water proof paper and outside is woven bags and then compression.
Carton packing: razor mesh coils are loading into hard cartoon boxes
